Kia Sorento IV (2020-2024) left side forward parking distance warning Wiring diagram
This page shows the only wiring diagram for the component.left side forward parking distance warning, which is found in the car Kia Sorento IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side forward parking distance warning (1 of 1)
12.3 INCH LCD
12.3 TFT DISPLAY
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
E-CAN TRANSCEIVER
FCA IND (4.2 INCH LCD)
FRONT CONSOLE SWITCH
GRN WIRE
GRN/ORG WIRE
GRY WIRE
ICU JUNCTION BLOCK
ICU-F
ILL
INSTRUMENT CLUSTER
INTERFACE
LEFT REVERSE PARKING DISTANCE WARNING
LEFT REVERSE PARKING DISTANCE WARNING (CENTER)
LEFT SIDE FORWARD PARKING DISTANCE WARNING
LID 1
LID 2
MCU
ORG/ WIRE
ORG/BLK WIRE
PDW-F/R SWITCH
PNK WIRE
RED WIRE
RED/ORG WIRE
RELAY ENERGIZED
RIGHT REVERSE PARKING DISTANCE WARNING
RIGHT REVERSE PARKING DISTANCE WARNING (CENTER)
SIG 3 GND
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Parking assistant circuit, hybrid w/ pca (3 of 3) -> LEFT SIDE FORWARD PARKING DISTANCE WARNING
