Kia Sorento IV (2020-2024) left luggage usb charge connector Wiring diagrams

10 WAY 8 WAY 14-WAY AWD ECU BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU/ORG WIRE BRN WIRE BRN/ORG WIRE DOOR LOCK RELAY DOOR UNLOCK RELAY DRIVER AIR VENTILATION SEAT BLOWER MOTOR DRIVER DOOR AREA UNIT DRIVER LUMBAR SUPPORT SWITCH DRIVER POWER OUTSIDE MIRROR DRIVER POWER SEAT SWITCH DRIVER SAFETY POWER WINDOW MODULE DRIVER SMART KEY OUTSIDE HANDLE FUEL PUMP CONTROL MODULE GRY WIRE HIGH MOUNTED STOP LAMP ICU JUNCTION BLOCK ICU-C IMS CONTROL MODULE LEFT BACKUP LAMP LEFT LICENSE LAMP LEFT LUGGAGE USB CHARGE CONNECTOR LEFT REAR COMBINATION LAMP LEFT REAR DOOR LOCK ACTUATOR LEFT REAR POWER WINDOW MODULE LEFT REAR POWER WINDOW SWITCH LEFT REAR SUNROOF MOTOR (GLASS) LEFT REAR SUNROOF MOTOR (ROLLER) NCA WIRE PNK/BLK WIRE POWER TAILGATE BUZZER POWER TAILGATE UNIT REAR CONSOLE POWER OUTLET REAR DEFOGGER REAR WIPER MOTOR RED/BLK WIRE RIGHT BACKUP LAMP RIGHT LICENSE LAMP T/TURN UNLOCK RELAY TAILGATE LATCH TAILGATE SWITCH (INNER) TAILGATE SWITCH (OUTSIDE) TRAILER MODULE W/ AUTO UP/DOWN, SAFETY W/ MEMORY W/ POWER SEAT W/ PTG W/ VENTILATION SEATS W/O AUTO UP/DOWN, SAFETY W/O CHILD LOCK W/ CHILD LOCK W/O MEMORY W/O PTG W/O VENTILATION SEATS

ACTIVE PURGE PUMP BLK WIRE BLK/ORG WIRE BRN/ORG WIRE BRN/YEL WIRE CVVD ACTUATOR DRIVER DOOR LOCK ACTUATOR DRIVER IMS SWITCH DRIVER POWER OUTSIDE MIRROR DRIVER SMART KEY OUTSIDE HANDLE ELECTRONIC A/C COMPRESSOR ELECTRONIC OIL PUMP SHIELD ELECTRONIC SHIFT DIAL ELECTRONIC WATER PUMP (ENGINE) ELECTRONIC WATER PUMP (HEV) FRONT CONSOLE SWITCH GRY WIRE GRY/ORG WIRE HPCU IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IMS CONTROL MODULE LEFT CENTER PARKING DISTANCE WARNING REVERSE SENSOR LEFT FRONT SEAT VENTILATION SWITCH LEFT FRONT SEAT WARMER SWITCH LEFT LUGGAGE USB CHARGE CONNECTOR LEFT PARKING DISTANCE WARNING REVERSE SENSOR LEFT REAR CORNER RADAR UNIT LEFT SIDE PARKING DISTANCE WARNING REVERSE SENSOR MASS AIR FLOW SENSOR (SHIELD) NCA WIRE PASSENGER DOOR LOCK ACTUATOR PASSENGER POWER OUTSIDE MIRROR PASSENGER SMART KEY OUTSIDE HANDLE POWER TAILGATE UNIT RIGHT CENTER PARKING DISTANCE WARNING REVERSE SENSOR RIGHT FRONT SEAT VENTILATION SWITCH RIGHT FRONT SEAT WARMER SWITCH RIGHT PARKING DISTANCE WARNING REVERSE SENSOR RIGHT SIDE PARKING DISTANCE WARNING REVERSE SENSOR W/ MEMORY W/ VENTILATION W/O VENTILATION

BLK WIRE BLU WIRE DETENT DRIVER IMS SWITCH GRN WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE ILL LEFT FRONT SEAT VENTILATION SWITCH LEFT FRONT SEAT WARMER SWITCH LEFT LUGGAGE USB CHARGE CONNECTOR LEFT REAR CONSOLE USB CHARGE CONNECTOR LEFT REAR POWER WINDOW SWITCH ORG/ WIRE OVERHEAD CONSOLE PASSENGER POWER WINDOW SWITCH PNK WIRE REAR A/C CONTROL MODULE RED WIRE RED/BLK WIRE RIGHT FRONT SEAT VENTILATION SWITCH RIGHT LUGGAGE USB CHARGE CONNECTOR RIGHT REAR CONSOLE USB CHARGE CONNECTOR RIGHT REAR POWER WINDOW SWITCH W/ AUTO UP/DOWN, SAFETY W/O AUTO UP/DOWN, SAFETY W/O VENTILATION YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

BLK WIRE BLU WIRE DETENT DRIVER IMS SWITCH FRONT CONSOLE SWITCH GRN WIRE GRY WIRE GRY/BLK WIRE ILL LEFT FRONT SEAT VENTILATION SWITCH LEFT FRONT SEAT WARMER SWITCH LEFT LUGGAGE USB CHARGE CONNECTOR LEFT REAR CONSOLE USB CHARGE CONNECTOR LEFT REAR POWER WINDOW SWITCH ORG/ WIRE OVERHEAD CONSOLE PASSENGER POWER WINDOW SWITCH PNK WIRE PPL/GRY WIRE REAR A/C CONTROL MODULE RED/BLK WIRE RIGHT FRONT SEAT VENTILATION SWITCH RIGHT FRONT SEAT WARMER SWITCH RIGHT LUGGAGE USB CHARGE CONNECTOR RIGHT REAR CONSOLE USB CHARGE CONNECTOR RIGHT REAR POWER WINDOW SWITCH W/ AUTO UP/DOWN, SAFETY W/O AUTO UP/DOWN, SAFETY W/O VENTILATION WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
