Kia Sorento IV (2020-2024) left front mode actuator Wiring diagram
This page shows the only wiring diagram for the component.left front mode actuator, which is found in the car Kia Sorento IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front mode actuator (1 of 1)
A/C BLOWER MOTOR CONTROL MODULE
B(+)
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/ORG WIRE
FRONT A/C BLOWER MOTOR
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HIGH VOLTAGE JUNCTION BLOCK
HV-A
INH
INTAKE ACTUATOR
LEFT FRONT MODE ACTUATOR
MOTOR
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PWM IN
PWR OUTPUT +
RED WIRE
RIGHT FRONT MODE ACTUATOR
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, hybrid (2 of 6) -> LEFT FRONT MODE ACTUATOR
