Kia Sorento IV (2020-2024) hall sens-pwr Wiring diagrams
This page contains all the electrical diagrams for the component. hall sens-pwr, in which he is found in the car Kia Sorento IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hall sens-pwr (1 of 2)
12.3 INCH LCD
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
HALL SENS 1 -
HALL SENS 2
HALL SENS GND
HALL SENS-PWR
ILL
INSTRUMENT CLUSTER
LEFT POWER TAILGATE SPINDLE (TOP OF LEFT "D" PILLAR)
LH SPINDLE MOTOR (-)
LH SPINDLE MOTOR HALL SENS 1
LH SPINDLE MOTOR HALL SENS 2
LH SPINDLE MOTOR HALL SENS GND
LH SPINDLE MOTOR HALL SENS PWR
LH SPINDLE MOTOR SHIELD
M-CAN
MCU
NCA WIRE
ORG/BLK WIRE
PNK/BLK WIRE
POWER TAILGATE BUZZER
POWER TAILGATE UNIT (LEFT SIDE OF CARGO AREA)
RED/BLK WIRE
REF SW
SHIELD GND
TAILGATE SW (INNER) ILL
TAILGATE SWITCH (INNER)
TAILGATE SWITCH (OUTSIDE)
TRANSCEIVER/
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power tailgate circuit, except hybrid (2 of 2) -> HALL SENS-PWR
