Kia Sorento IV (2020-2024) gry Wiring diagrams

This page contains all the electrical diagrams for the component. gry, in which he is found in the car Kia Sorento IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram gry (91 of 227)

Wiring diagram gry for Kia Sorento IV (2020-2024) (91 of 227)

Get access

B+ GND BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR DOOR OPEN SWITCH DRIVER SMART KEY OUTSIDE HANDLE GLOVE BOX LAMP) GRY WIRE IBU LAMP LED STABILITY LEFT LAMP LEFT MAP LAMP LEFT PERSONAL LAMP LEFT VANITY LAMP LMP MEM NCA WIRE ORG/BLK WIRE P-CAN HIGH P-CAN LOW PASSENGER SMART KEY OUTSIDE HANDLE PCB PUDDLE/POCKET PWR RED WIRE RIGHT LAMP RIGHT MAP LAMP RIGHT PERSONAL LAMP RIGHT VANITY LAMP ROOM ROOM LAMP ROOM LAMP (W/ LED) ROOM LAMP SWITCH W/ LED W/ SMART KEY W/ SUNROOF W/O SUNROOF WHT WIRE WHT/ORG WIRE

Go to component -> Courtesy lamps circuit, except hybrid (2 of 2) -> GRY WIRE

Wiring diagram gry (92 of 227)

Wiring diagram gry for Kia Sorento IV (2020-2024) (92 of 227)

Get access

ATM SHIFT LEVER B-CAN B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE CLUSTER FUSE COMPUTER DATA LINES SYSTEM DETENT DETENT OUT FRONT CONSOLE SWITCH GND (BCM) GND SIG 3 GRN WIRE GROUND GRY WIRE GRY/ORG WIRE HEAD (LOW) HOT W/ IBU (RIGHT SIDE OF HVAC UNIT) ICU JUNCTION BLOCK ICU-D ICU-F ICU-G ICU-H ILL ILL (-) OUT INSTRUMENT CLUSTER IPS IPS CONTROL IPS CONTROL MODULE LIGHT SWITCH LIGHT SWITCH OUT LOW HIGH M-CAN TRANSCEIVER MICOM MULTI- FUNCTION SWITCH OFF ORG/ WIRE PNK WIRE RED WIRE RED/BLK WIRE RELAY ENERGIZED SIGNAL SSB RING ILL OUT TAIL TAIL LAMP SW CKT (UNPLACED) W/O VENTILATION WIPER, LIGHT YEL WIRE YEL/ORG WIRE

Go to component -> Instrument illumination circuit, except hybrid (1 of 3) -> GRY WIRE

Wiring diagram gry (93 of 227)

Wiring diagram gry for Kia Sorento IV (2020-2024) (93 of 227)

Get access

BLK WIRE BLU WIRE DETENT DRIVER IMS SWITCH GRN WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE ILL LEFT FRONT SEAT VENTILATION SWITCH LEFT FRONT SEAT WARMER SWITCH LEFT LUGGAGE USB CHARGE CONNECTOR LEFT REAR CONSOLE USB CHARGE CONNECTOR LEFT REAR POWER WINDOW SWITCH ORG/ WIRE OVERHEAD CONSOLE PASSENGER POWER WINDOW SWITCH PNK WIRE REAR A/C CONTROL MODULE RED WIRE RED/BLK WIRE RIGHT FRONT SEAT VENTILATION SWITCH RIGHT LUGGAGE USB CHARGE CONNECTOR RIGHT REAR CONSOLE USB CHARGE CONNECTOR RIGHT REAR POWER WINDOW SWITCH W/ AUTO UP/DOWN, SAFETY W/O AUTO UP/DOWN, SAFETY W/O VENTILATION YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

Go to component -> Instrument illumination circuit, except hybrid (2 of 3) -> GRY WIRE

Wiring diagram gry (94 of 227)

Wiring diagram gry for Kia Sorento IV (2020-2024) (94 of 227)

Get access

B-CAN B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE CLUSTER FUSE COMPUTER DATA LINES SYSTEM DETENT OUT E-CAN GND (BCM) GND SIG 3 GRN WIRE GRN/ORG WIRE GROUND GRY WIRE GRY/BLK WIRE HEAD (LOW) HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED IBU (RIGHT SIDE OF HVAC UNIT) ICU JUNCTION BLOCK ICU-D ICU-F ICU-G ICU-H ILL ILL (-) OUT INSTRUMENT CLUSTER IPS IPS CONTROL IPS CONTROL MODULE LIGHT SWITCH LIGHT SWITCH OUT LOW HIGH M-CAN TRANSCEIVER MEMORY FUSE MICOM MULTI- FUNCTION SWITCH OFF ORG/ WIRE PNK WIRE RED WIRE RED/BLK WIRE RELAY ENERGIZED SIGNAL SSB RING ILL OUT TAIL TAIL LAMP SW CKT (UNPLACED) TRANSCEIVER/ W/O VENTILATION WHT/BLK WIRE WIPER, LIGHT YEL WIRE

Go to component -> Instrument illumination circuit, hybrid (1 of 3) -> GRY WIRE

Wiring diagram gry (95 of 227)

Wiring diagram gry for Kia Sorento IV (2020-2024) (95 of 227)

Get access

A/V, NAVIGATION HEAD UNIT AUDIO BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CLOCKSPRING DOWN FRONT A/C CONTROL PANEL FRONT WIRELESS CHARGER INDICATOR GRY WIRE GRY/BLK WIRE ILL LEFT FRONT USB CHARGE CONNECTOR LEFT STEERING WHEEL REMOTE CONTROL SWITCH PNK WIRE RED/BLK WIRE RHEOSTAT RIGHT FRONT SEAT WARMER SWITCH RIGHT FRONT USB CHARGE CONNECTOR RIGHT STEERING WHEEL REMOTE CONTROL SWITCH START/STOP BUTTON SWITCH STEERING WHEEL) USB JACK W/ NAVIGATION W/O NAVIGATION WHT WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Instrument illumination circuit, hybrid (3 of 3) -> GRY WIRE

Wiring diagram gry (96 of 227)

Wiring diagram gry for Kia Sorento IV (2020-2024) (96 of 227)

Get access

B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE CINCHING MOTOR (+) MOTOR GND CINCHING MOTOR (-) MOTOR PWR COMPUTER DATA LINES SYSTEM CRASH PAD SWITCH (LEFT END OF DASH) E/R JUNCTION BLOCK FULL LOCK FULL LOCK SW GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE HALF LOCK HALF LOCK SW HOME POSITION HOME POSITION SW HOT AT ALL TIMES HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED ICU JUNCTION BLOCK ICU-D ICU-E ICU-H ILL IPS CONTROL MODULE LEFT ANTI-PINCH LH ANTI PINCH PWR LH ANTI-PINCH GND M-CAN HIGH M-CAN LOW MEMORY FUSE MEMORY PWR MOTOR MULTI FUSE 2 NCA WIRE ORG/ WIRE PNK WIRE POWER TAILGATE FUSE POWER TAILGATE SWITCH POWER TAILGATE UNIT (LEFT SIDE OF CARGO AREA) PTG BUZZER PWR RED WIRE REF RH ANTI PINCH PWR RH ANTI-PINCH GND RIGHT ANTI-PINCH SW GND SWITCH TAILGATE FULL LOCK SWITCH TAILGATE LATCH (BOTTOM CENTER OF TAILGATE) TAILGATE SW (INNER) LOCK TAILGATE SW (INNER) OPEN CRASH PAD SW TAILGATE SWITCH (OUTSIDE) WHT WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE

Go to component -> Power tailgate circuit, except hybrid (1 of 2) -> GRY WIRE

Wiring diagram gry (97 of 227)

Wiring diagram gry for Kia Sorento IV (2020-2024) (97 of 227)

Get access

B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE CINCHING MOTOR (+) COMPUTER DATA LINES SYSTEM CRASH PAD SWITCH (LEFT END OF DASH) E/R JUNCTION BLOCK FULL LOCK FULL LOCK SW GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE HALF LOCK HALF LOCK SW HOME POSITION HOT AT ALL TIMES HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED ICU JUNCTION BLOCK ICU-D ICU-E ICU-H ILL IPS CONTROL MODULE LEFT ANTI-PINCH LH ANTI-PINCH GND MEMORY FUSE MEMORY PWR MOTOR MOTOR GND MULTI FUSE 2 NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE POWER TAILGATE FUSE POWER TAILGATE SWITCH POWER TAILGATE UNIT (LEFT SIDE OF CARGO AREA) PTG BUZZER B-CAN LOW PWR RED WIRE REF REF SW RH ANTI PINCH PWR RH ANTI-PINCH GND RIGHT ANTI-PINCH SW GND SWITCH SYSTEM GND TAILGATE FULL LOCK SWITCH TAILGATE LATCH (BOTTOM CENTER OF TAILGATE) TAILGATE OPEN/CLOSE SW TAILGATE SW (INNER) LOCK LH ANTI PINCH PWR TAILGATE SW (INNER) OPEN HOME POSITION SW TAILGATE SWITCH (OUTSIDE) WHT WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE

Go to component -> Power tailgate circuit, hybrid (1 of 2) -> GRY WIRE

Wiring diagram gry (98 of 227)

Wiring diagram gry for Kia Sorento IV (2020-2024) (98 of 227)

Get access

12.3 INCH LCD BLK WIRE BLK/ORG WIRE BLU/ORG WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE HALL SENS 1 - HALL SENS 2 HALL SENS GND HALL SENS-PWR ILL INSTRUMENT CLUSTER LEFT POWER TAILGATE SPINDLE (TOP OF LEFT "D" PILLAR) LH SPINDLE MOTOR (-) LH SPINDLE MOTOR HALL SENS 1 LH SPINDLE MOTOR HALL SENS 2 LH SPINDLE MOTOR HALL SENS GND LH SPINDLE MOTOR HALL SENS PWR LH SPINDLE MOTOR SHIELD M-CAN MCU NCA WIRE ORG/BLK WIRE PNK/BLK WIRE POWER TAILGATE BUZZER POWER TAILGATE UNIT (LEFT SIDE OF CARGO AREA) RED/BLK WIRE TAILGATE SWITCH TAILGATE SWITCH (OUTSIDE) TRANSCEIVER/ WHT WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Power tailgate circuit, hybrid (2 of 2) -> GRY WIRE

Wiring diagram gry (99 of 227)

Wiring diagram gry for Kia Sorento IV (2020-2024) (99 of 227)

Get access

12.3 INCH LCD BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR LOCK FUSE DOOR LOCK RELAY DOOR UNLOCK RELAY FUEL FILLER ACTUATOR FULL LOCK SW FULL LOCK SWITCH FULL OPEN SW FULL OPEN SWITCH GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C ICU-E ICU-H INSTRUMENT CLUSTER IPS CONTROL MODULE M-CAN M-CAN HIGH M-CAN LOW MCU MOTOR ORG/ WIRE OUTSIDE PTC MOTOR RELAY CONTROL T/TURN UNLOCK RELAY TAILGATE LATCH TAILGATE OPEN FUSE TAILGATE RELAY TAILGATE SW TAILGATE SWITCH (OUTSIDE) TRANSCEIVER/ W/ TWO TURN UNLOCK W/O TWO TURN UNLOCK WHT WIRE YEL WIRE

Go to component -> Tailgate & fuel door release circuit, except hybrid -> GRY WIRE

Wiring diagram gry (100 of 227)

Wiring diagram gry for Kia Sorento IV (2020-2024) (100 of 227)

Get access

12.3 INCH LCD B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR LOCK FUSE DOOR LOCK RELAY FUEL FILLER ACTUATOR FULL LOCK SW FULL LOCK SWITCH FULL OPEN SW FULL OPEN SWITCH GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C ICU-E ICU-H INSTRUMENT CLUSTER IPS CONTROL MODULE M-CAN MCU MOTOR ORG/ WIRE OUTSIDE PPL/ORG WIRE PTC MOTOR RED WIRE RELAY CONTROL TAILGATE LATCH TAILGATE OPEN FUSE TAILGATE RELAY TAILGATE SW TAILGATE SWITCH (OUTSIDE) TRANSCEIVER/ TWO TURN UNLOCK RELAY WHT WIRE YEL WIRE

Go to component -> Tailgate & fuel door release circuit, hybrid -> GRY WIRE
