Kia Sorento IV (2020-2024) door lock door unlock Wiring diagrams

AJAR BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE CHILD LOCK CHILD LOCK RELAY CTRL CHILD SWITCH CHILD UNLOCK RELAY CTRL DOOR AJAR DOOR UNLOCK LOCK DOOR LOCK DOOR UNLOCK DRIVER DOOR LOCK ACTUATOR (TOP REAR OF DRIVER DOOR) DRIVER DOOR LOCK/UNLOCK SIGNAL DRIVER DOOR SWITCH EXCEPT HYBRID HYBRID FUEL FILLER ACTUATOR GRN WIRE GRY WIRE HOOD SWITCH HYBRID EXCEPT HYBRID ICU JUNCTION BLOCK ICU-A ICU-E ICU-F IPS CONTROL MODULE LEFT REAR DOOR LOCK ACTUATOR (TOP REAR OF LEFT REAR DOOR) LH REAR DOOR CHILD LOCK SIGNAL LH REAR DOOR LOCK/ UNLOCK SIGNAL LH REAR DOOR SWITCH NCA WIRE ORG/ WIRE PASSENGER DOOR LOCK/UNLOCK SIGNAL PASSENGER DOOR SWITCH PNK WIRE PNK/BLK WIRE RED WIRE RH REAR DOOR DOOR LOCK/ CHILD LOCK UNLOCK SIGNAL SIGNAL RH REAR RH REAR DOOR SWITCH W/O CHILD LOCK W/ CHILD LOCK WHT WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE

AJAR BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE CHILD LOCK CHILD LOCK RELAY CTRL CHILD SWITCH CHILD UNLOCK RELAY CTRL DOOR AJAR DOOR UNLOCK LOCK DOOR LOCK DOOR UNLOCK DRIVER DOOR LOCK ACTUATOR (TOP REAR OF DRIVER DOOR) DRIVER DOOR LOCK/UNLOCK SIGNAL DRIVER DOOR SWITCH EXCEPT HYBRID HYBRID FUEL FILLER ACTUATOR GRN WIRE GRY WIRE HOOD SWITCH HYBRID EXCEPT HYBRID ICU JUNCTION BLOCK ICU-A ICU-E ICU-F IPS CONTROL MODULE LEFT REAR DOOR LOCK ACTUATOR (TOP REAR OF LEFT REAR DOOR) LH REAR DOOR CHILD LOCK SIGNAL LH REAR DOOR LOCK/ UNLOCK SIGNAL LH REAR DOOR SWITCH NCA WIRE ORG/ WIRE PASSENGER DOOR LOCK/UNLOCK SIGNAL PASSENGER DOOR SWITCH PNK WIRE PNK/BLK WIRE RED WIRE RH REAR DOOR DOOR LOCK/ CHILD LOCK UNLOCK SIGNAL SIGNAL RH REAR RH REAR DOOR SWITCH W/O CHILD LOCK W/ CHILD LOCK WHT WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE
