Kia Sorento IV (2020-2024) blk Wiring diagrams

This page contains all the electrical diagrams for the component. blk, in which he is found in the car Kia Sorento IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

blk wiring diagram (171 of 281)

BLK WIRE BLU WIRE BRN WIRE DRIVER LUMBAR SUPPORT MOTOR (FWD/BWD) DRIVER LUMBAR SUPPORT SWITCH EXCEPT HYBRID FWD BWD GRN WIRE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C LUMBAR SUPPORT MOTOR MEMORY POWER NCA WIRE ORG/BLK WIRE P/SEAT (DRV) FUSE PNK/BLK WIRE RED WIRE

Go to component -> Driver power seat circuit, 2-way -> BLK WIRE

blk wiring diagram (172 of 281)

BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE BRN/ORG WIRE DRIVER FRONT HEIGHT ADJUSTER MOTOR DRIVER LUMBAR RECLINING MOTOR DRIVER POWER SEAT SWITCH DRIVER REAR HEIGHT ADJUSTER MOTOR DRIVER RECLINING MOTOR DRIVER SLIDE MOTOR EXCEPT HYBRID GRN WIRE GRY WIRE HEIGHT MOTOR DN HEIGHT MOTOR UP HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C MEMORY POWER NCA WIRE ORG/ WIRE P/SEAT (DRV) FUSE PNK WIRE RECLINING BWD RECLINING FWD RED WIRE SLIDE MOTOR (BWD) SLIDE MOTOR (FWD) TILT MOTOR DN HEIGHT MOTOR DN TILT MOTOR UP HEIGHT MOTOR UP W/ VENTILATION SEAT W/O VENTILATION SEAT WHT WIRE YEL WIRE

Go to component -> Driver power seat circuit, 8-way -> BLK WIRE

blk wiring diagram (173 of 281)

B-CAN BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/ORG WIRE CLOCKSPRING COMPUTER DATA LINES SYSTEM FRONT CONSOLE SWITCH GRY WIRE HEATED PAD HIGH LOW HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C ICU-E ICU-F ICU-H ILL IPS CONTROL IPS CONTROL MODULE NCA WIRE NTC- POWER RED WIRE RED/BLK WIRE RED/WHT WIRE STEERING WHEEL HEATED MODULE STEERING WHEEL HEATED SWITCH STEERING WHEEL HEATER STEERING WHEEL HEATER SWITCH STEERING WHEEL HEATER SWITCH IND STEERING WHEEL) WHT WIRE YEL WIRE

Go to component -> Heated steering wheel circuit -> BLK WIRE

blk wiring diagram (174 of 281)

BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE BRN/BLK WIRE EXCEPT HYBRID GRN WIRE GRN/BLK WIRE GRY WIRE HEIGHT MTR DN HEIGHT MTR UP HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C LUMBAR SUPPORT BWD LUMBAR SUPPORT FWD LUMBAR SUPPORT MOTOR MEMORY PWR NCA WIRE ORG/ WIRE ORG/BLK WIRE P/SEAT PASS FUSE PASSENGER FRONT HEIGHT ADJUSTER MOTOR PASSENGER LUMBAR RECLINING MOTOR PASSENGER LUMBAR SUPPORT MOTOR PASSENGER POWER SEAT SWITCH PASSENGER REAR HEIGHT ADJUSTER MOTOR PASSENGER RECLINING MOTOR PASSENGER SLIDE MOTOR PNK WIRE RECLINING BWD RECLINING FWD RED WIRE RED/BLK WIRE SLIDE MOTOR (BWD) SLIDE MOTOR (FWD) TILT MTR DN HEIGHT MTR DN TILT MTR UP HEIGHT MTR UP WHT WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Passenger power seat circuit, 10-way w/o walk in switch -> BLK WIRE

blk wiring diagram (175 of 281)

BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE EXCEPT HYBRID GRN WIRE GRY WIRE HEIGHT MTR DN HEIGHT MTR UP HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C MEMORY PWR NCA WIRE ORG/ WIRE ORG/BLK WIRE P/SEAT PASS FUSE PASSENGER FRONT HEIGHT ADJUSTER MOTOR PASSENGER LUMBAR RECLINING MOTOR PASSENGER POWER SEAT SWITCH PASSENGER REAR HEIGHT ADJUSTER MOTOR PASSENGER RECLINING MOTOR PASSENGER SLIDE MOTOR PNK WIRE RECLINING BWD RECLINING FWD RED/BLK WIRE SLIDE MOTOR (BWD) SLIDE MOTOR (FWD) TILT MOTOR DN HEIGHT MTR DN TILT MOTOR UP HEIGHT MTR UP WHT WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Passenger power seat circuit, 8-way w/o walk in switch -> BLK WIRE

blk wiring diagram (176 of 281)

BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLK WIRE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE HEIGHT MTR DN HEIGHT MTR UP HEIGHT MTR UP PNK HEIGHT MTR DN WIRE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C MEMORY PWR ORG/ WIRE ORG/BLK WIRE P/SEAT PASS FUSE PASSENGER FRONT HEIGHT ADJUSTER MOTOR PASSENGER LUMBER RECLINING MOTOR PASSENGER POWER SEAT SWITCH PASSENGER REAR HEIGHT ADJUSTER MOTOR PASSENGER RELAY UNIT PASSENGER SLIDE MOTOR PNK WALK IN SLIDE FWD WIRE PNK WIRE PNK/BLK WIRE RECLINING BWD RECLINING FWD RECLINING MOTOR BWD RECLINING MOTOR FWD RED/BLK WIRE SLIDE BWD SLIDE FWD SLIDE MOTOR (BWD) SLIDE MOTOR (FWD) WALK IN RECLINING BWD WALK IN RECLINING FWD WALK IN SLIDE BWD WALK IN SLIDE FWD WALK IN SWITCH WHT WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE

Go to component -> Passenger power seat circuit, 8-way w/ walk in switch -> BLK WIRE

blk wiring diagram (177 of 281)

B-CAN TRANSCEIVER BCW IND BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE COM OUT COMPUTER DATA LINES SYSTEM DEFOGGER DEFOGGER SYSTEM DEFOGGER, EXTERIOR LIGHTS SYSTEMS DOOR CAMERA DOWN DRIVER DOOR AREA UNIT (CENTER OF DRIVER DOOR) DRIVER POWER OUTSIDE MIRROR EXCEPT HYBRID FOLDING FOLDING MOTOR GRN WIRE GRN/ORG WIRE IPS (MIRROR) LEFT LEFT RIGHT LIMIT SWITCH MCU NAVIGATION SYSTEM NCA WIRE ORG/BLK WIRE OSM POSITION SWITCH LEFT OSM SELECT SWITCH OUTSIDE MIRROR PNK/BLK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/ORG WIRE RIGHT SYMBOL ILL TURN LAMP UNFOLDING UP DOWN V OUT VCC VOLTAGE REGULATOR WHT WIRE YEL/BLK WIRE

Go to component -> Power mirrors circuit (1 of 2) -> BLK WIRE

blk wiring diagram (178 of 281)

BCW IND BLK WIRE BLU/BLK WIRE BLU/ORG WIRE BRN/BLK WIRE BRN/ORG WIRE DEFOGGER DEFOGGER SYSTEM DEFOGGER, EXTERIOR LIGHTS SYSTEMS EXCEPT HYBRID FOLDING MOTOR GRN/ORG WIRE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C ICU-G LEFT RIGHT LIMIT SWITCH MODULE 2 FUSE MODULE 9 FUSE NAVIGATION SYSTEM NCA WIRE ORG/BLK WIRE OUTSIDE MIRROR PASSENGER DOOR CAMERA PASSENGER POWER OUTSIDE MIRROR PNK WIRE PNK/BLK WIRE RED WIRE RELAY ENERGIZED TURN LAMP UP DOWN V OUT YEL/BLK WIRE

Go to component -> Power mirrors circuit (2 of 2) -> BLK WIRE

blk wiring diagram (179 of 281)

BACK HEATER BLK WIRE BLK/ORG WIRE BRN WIRE BRN/ORG WIRE CUSHION HEATER GRN WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE ILL LEFT FRONT SEAT VENTILATION SWITCH NCA WIRE NTC- ON/START INPUT ORG/ WIRE ORG/BLK WIRE PASSENGER AIR VENTILATION SEAT BLOWER MOTOR PASSENGER AIR VENTILATION SEAT WARMER PASSENGER SEAT BACK WARMER PASSENGER SEAT CUSHION WARMER PNK/BLK WIRE PWR RED WIRE RED/BLK WIRE RIGHT FRONT SEAT VENTILATION SWITCH W/ POWER SEAT WHT WIRE WHT/ORG WIRE YEL WIRE

Go to component -> Seat ventilation circuit (2 of 2) -> BLK WIRE

blk wiring diagram (180 of 281)

BLK WIRE BLU WIRE CRUISE CONTROL SYSTEM EXCEPT HYBRID FOLDING SW GRN WIRE GRY WIRE HOT AT ALL TIMES HYBRID EXCEPT HYBRID ICU JUNCTION BLOCK ICU-C MEMORY PWR PNK WIRE PNK/BLK WIRE PPL/ORG WIRE REAR SEAT FOLDING SWITCH RED WIRE VEHICLE SPD WALK IN SW

Go to component -> Second row folding seat circuit -> BLK WIRE
