Rear wiper/washer circuit for Kia Sorento I facelift (2006-2011)
Rear wiper/washer circuit
BCM (BEHIND CENTER OF DASH)
BLK WIRE
BLU/BLK WIRE
E/R-G
FRONT WIPER/WASHER CIRCUIT
GRN WIRE
GRN/BLK WIRE
HOT IN ON
I/P JUNCTION BOX (BEHIND LEFT KICK PANEL)
I/P-B
JOINT
MULTI- FUNCTION SWITCH
NCA WIRE
OFF INT
ON REAR WIPER SWITCH
R/WPR FUSE
REAR WASHER SWITCH
REAR WIPER CONTROLLER (CENTER OF TAILGATE)
REAR WIPER MOTOR (CENTER OF TAILGATE)
RED/ORG WIRE
TAIL GATE GLASS ACTUATOR
VOLTAGE CONTROLLER
WHT WIRE
WHT/ORG WIRE
YEL/ORG WIRE
