Tailgate release circuit for Kia Sorento I facelift (2006-2011)
Tailgate release circuit
21 102-3 13 102-2
BCM (BEHIND CENTER OF DASH)
BLK WIRE
BLU WIRE
HOT AT ALL TIMES D/LK FUSE
I/P JUNCTION BOX (BEHIND LEFT KICK PANEL)
I/P-C
IC MODULE (UNDER LEFT END OF DASH)
ORG/ WIRE
RED/BLK WIRE
RED/ORG WIRE
TAILGATE GLASS ACTUATOR (CENTER OF TAILGATE) CLOSE
TAILGATE GLASS ILL SWITCH
TAILGATE GLASS OPEN RELAY
