Charging circuit for Kia Sorento I facelift (2006-2011)

ALT FUSIBLE LINK BATTERY BCM (BEHIND CENTER OF DASH) BLK WIRE BLU WIRE BRN WIRE CHARGE IND DRL CONTROL MODULE (BEHIND LEFT SIDE OF DASH) E/R JUNCTION BOX (AT LEFT SIDE OF ENGINE COMPT) E/R-G ECM (RIGHT REAR CORNER OF ENGINE COMPT) GENERATOR HOT IN ON OR START I/P JUNCTION BOX I/P-A INSTRUMENT CLUSTER JOINT CONNECTOR METER FUSE NCA WIRE P/TRN FUSE POWER DISTRIBUTION SYSTEM RED WIRE WHT WIRE
