Kia Sorento I facelift (2006-2011) Computer data lines circuit

A/C CONTROL MODULE (AUTOMATIC A/C) (IN CENTER OF DASH) BCM (BEHIND CENTER OF DASH) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE CAN HI CAN LO DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) E/R JUNCTION BOX (AT LEFT SIDE E/R-A E/R-D E/R-G ECM (RIGHT REAR CORNER OF ENGINE COMPT) EST CONTROL MODULE (UNDER RIGHT SIDE OF DASH) FUEL PUMP RELAY GASOLINE BOX GRN WIRE GRN/ORG WIRE HIGH COOLING FAN RELAY HOT AT ALL TIMES I/P JUNCTION BOX DRL/ (BEHIND LEFT OBD 2 KICK PANEL) FUSE I/P-A I/P-D JOINT CONNECTOR K LINE MULTIPURPOSE CHECK CONNECTOR (LEFT REAR OF ENGINE COMPT) OF ENGINE COMPT) RED WIRE RED/BLK WIRE RED/ORG WIRE SRS CONTROL MODULE (UNDER REAR OF CENTER CONSOLE) STOP ENG FUSE FUSE TCM (UNDER RIGHT SIDE OF DASH) TIRE PRESSURE MONITORING MODULE (BEHIND CENTER OF DASH) TOD CONTROL MODULE (UNDER RIGHT SIDE OF DASH) W/ TOD W/ W/O ESC ESC W/O TOD YEL WIRE YEL/BLK WIRE
