Kia Sorento I facelift (2006-2011) (under right Wiring diagram
This page shows the only wiring diagram for the component.(under right, which is found in the car Kia Sorento I facelift (2006-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (under right (1 of 1)
BACK WARMER
BLK WIRE
BLU WIRE
CUSHION WARMER
DRIVER POWER SEAT
DRIVER SEAT WARMER RELAY
DRIVER SEAT WARMER SWITCH
F/WPR FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
I/P JUNCTION BOX (BEHIND LEFT KICK PANEL)
I/P-A
I/P-B
I/P-D
I/P-E
IC MODULE (UNDER LEFT END OF DASH)
ILL
ILL IND
IND
ORG/ WIRE
PASSENGER SEAT WARMER (IN FRONT PASSENGER'S SEAT)
PASSENGER SEAT WARMER RELAY
PASSENGER SEAT WARMER SWITCH
R/WPR FUSE
RED WIRE
S/WARMER FUSE
SEAT/D FUSE
THERMOSTAT
WHT WIRE
YEL WIRE
Go to component -> Power seats circuit -> (UNDER RIGHT
