Kia Sorento I facelift (2006-2011) linear sol i/c linear sol lu sol h lr/c linear sol fr/b linear sol pl Wiring diagram

AUTO MODULE (ON RIGHT SIDE OF TRANSMISSION) BACK-UP LP RLY TURBINE 2 TURBINE 1 BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOWN SHIFT E/R-G GRN WIRE GRN/BLK WIRE GRN/RED WIRE GROUND GROUND GROUND GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES E/R JUNCTION BOX (AT LEFT SIDE OF ENGINE COMPT) P/TRN FUSE HOT IN ON OR START I/P JUNCTION BOX (BEHIND LEFT KICK PANEL) I/P-A I/P-C I/P-D ILL LINEAR SOL D/C LINEAR SOL I/C LINEAR SOL LU SOL H LR/C LINEAR SOL FR/B LINEAR SOL PL MANUAL SELECT SWITCH METER FUSE NCA WIRE NORMAL NOT USED ORG/ WIRE PL SOL- ENOID SOL- ENOID PNK WIRE PWM SIGNAL SOL SUPPLY RED WIRE RED/BLK WIRE RED/ORG WIRE SOL- ENOID SOL- SOL- SOL- ENOID ENOID ENOID L/U SOLENOID SOLENOID VALVE SPORT MODE SWITCH STOP FUSE STOP LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET) TO EEP ROM BOX ASSEMBLY (DIAGRAM 2 OF 2) TO EEP ROM OFF BOX ASSEMBLY (DIAGRAM 2 OF 2) TO TCM (DIAGRAM 2 OF 2) TRANSAXLE RANGE SWITCH TURBINE SENSOR TO EEP ROM BOX ASSEMBLY (DIAGRAM 2 OF 2) UP SHIFT 6 8 7 WHT WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE
