Kia Sorento I facelift (2006-2011) high tail gate mounted glass actuator stop lamp wiring diagram
This page shows the only wiring diagram for the component.high tail gate mounted glass actuator stop lamp, which is found in the car Kia Sorento I facelift (2006-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
high tail gate mounted glass actuator stop lamp wiring diagram (1 of 1)
A/C CONTROL MODULE
AMBIENT TEMPERATURE SENSOR
AUTO LIGHT CONTROL MODULE
AUTOMATIC A/C MANUAL A/C
BLK WIRE
BLU WIRE
CARGO ROOM LAMP
CENTER FRONT POWER POWER OUTLET OUTLET
COOLING FAN MOTOR
DATA LINK CONNECTOR
DRIVER POWER SEAT
DRIVER SEAT BELT SWITCH
DRIVER SEAT WARMER SWITCH
ECT, RHEOSTAT TOD, SNOW SWITCH
FET (FIELD EFFECT TRANSISTOR)
FROM
FRONT CIGARETTE LIGHTER, ILLUMINATION
FUEL PUMP MOTOR, FUEL SENDER
GLOVE REAR BOX DEFOGGER ILLUMINATION SWITCH
GRN/ORG WIRE
HIGH TAIL GATE MOUNTED GLASS ACTUATOR STOP LAMP
INSTRUMENT DRL CONTROL CLUSTER MODULE
KEYLESS RELAY BCM
LEFT LICENSE LAMP REAR POWER OUTLET
LEFT REAR BACK POWER WARNING WINDOW CONTROL SWITCH MODULE
LEFT REAR COMBINATION LAMP
LEFT REAR DRIVER DOOR DOOR SWITCH SWITCH
MANUAL A/C
NCA WIRE
OC SENSOR
OUTSIDE MIRROR DEFOGGER RELAY
PASSENGER DIGITAL SEAT CLOCK, WARMER TPMS DISPLAY SWITCH
PASSENGER DOOR SWITCH
PASSENGER SEAT BELT SWITCH
PASSENGER SEAT WARMER
PREMIUM AUDIO
REAR WIPER CONTROLLER TCM
RELAY BOX (BEHIND RIGHT END OF DASH)
RIGHT FRONT FOG LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT HEAD- LAMP
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP
RIGHT REAR DOOR SWITCH
RIGHT REAR POWER WINDOW SWITCH
TAIL GATE KEY SWITCH
TIRE PRESSURE MONITORING MODULE
TRAILER POWER OUTLET
VEHICLE MASS SPEED AIR FLOW IGNITION SENSOR SENSOR COIL SHIELD
WASHER FLUID LEVEL SENSOR
WASHER MOTOR
WINDSHIELD DEFOGGER SWITCH
Go to component -> Ground distribution circuit (2 of 2) -> HIGH TAIL GATE MOUNTED GLASS ACTUATOR STOP LAMP
