Kia Sorento I facelift (2006-2011) eng run in sig Wiring diagram
This page shows the only wiring diagram for the component.eng run in sig, which is found in the car Kia Sorento I facelift (2006-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eng run in sig (1 of 1)
BCM (BEHIND CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
DEF RLY CTRL
DEF SW
ENG RUN IN SIG
F/WPR FUSE
HOT AT ALL TIMES
HOT IN ON
I/P-A
I/P-E
ILL 6 3
IND
INSTRUMENT PANEL JUNCTION BOX (BEHIND LEFT KICK PANEL)
RED WIRE
RED/BLK WIRE
STARTING/ CHARGING SYSTEM
W/SHD FUSE
WINDSHIELD DEFOGGER
WINDSHIELD DEFOGGER RELAY
WINDSHIELD DEFOGGER SWITCH
YEL WIRE
Go to component -> Heated windshield circuit -> ENG RUN IN SIG
