Kia Sorento I facelift (2006-2011) eep rom box assembly Wiring diagrams
This page contains all the electrical diagrams for the component. eep rom box assembly, in which he is found in the car Kia Sorento I facelift (2006-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
eep rom box assembly wiring diagram (1 of 2)
AUTO MODULE (ON RIGHT SIDE OF TRANSMISSION)
BACKUP LAMP RELAY
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
CAN HIGH
CAN LOW SEL 1
COMPUTER DATA LINES SYSTEM
EEP ROM BOX ASSEMBLY
EST, TOD, SNOW SWITCH
FROM OIL TEMP SENSOR (DIAGRAM 1 OF 2)
FROM TRANS- AXLE RANGE SWITCH (DIAGRAM
FROM TRANSAXLE RANGE SWITCH
FROM TURBINE SENSOR (DIAGRAM 1 OF 2)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
ILL
INSTRUMENT CLUSTER
LOW IND
MICOM
MODE SELECT SW SNOW SWITCH
NCA WIRE
OIL PRESSURE SWITCH
OIL TEMPERATURE SENSOR
ORG/ WIRE
PNK WIRE
PWM SIGNAL
RED WIRE
RED/BLK WIRE
RELAY BOX (BEHIND RIGHT END OF DASH)
SEL 3 SEL 2 VSP 1
SOL SUPPLY
TCM (UNDER RIGHT SIDE OF DASH)
VIGN-OUT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> A/t circuit (2 of 2) -> EEP ROM BOX ASSEMBLY
eep rom box assembly wiring diagram (2 of 2)
AUTO MODULE (ON RIGHT SIDE OF TRANSMISSION)
BACK WARNING CONTROL MODULE (BEHIND LEFT QUARTERPANEL)
BACKUP LAMP RELAY
BACKUP LAMP RLY
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
EEP ROM BOX ASSEMBLY
GRN WIRE
HOME LINK CONNECTOR
HOT IN ON OR START
I/P JUNCTION BOX (BEHIND LEFT KICK PANEL)
I/P-A
LEFT REAR COMBINATION LAMP LEFT BACKUP LAMP
METER FUSE
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RELAY BOX (BEHIND RIGHT END OF DASH)
RIGHT REAR RIGHT COMBINATION BACKUP LAMP LAMP
SW 1
SW 2
SW 4
TCM (UNDER RIGHT SIDE OF DASH)
TRANSAXLE RANGE SWITCH
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Backup lamps circuit -> EEP ROM BOX ASSEMBLY
