Kia Sorento I facelift (2006-2011) dimmer/ passing switch low high flash Wiring diagram
This page shows the only wiring diagram for the component.dimmer/ passing switch low high flash, which is found in the car Kia Sorento I facelift (2006-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dimmer/ passing switch low high flash (1 of 1)
BCM (BEHIND CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
DIMMER/ PASSING SWITCH LOW HIGH FLASH
E/R-D
E/R-E
E/R-G
E/R-H
EXT FUSE
FRONT FOG IND
FRONT FOG LAMP RELAY
FRONT FOG LAMP SW
FRONT FOG- LAMP SWITCH OFF
GRN WIRE
GRN/ORG WIRE
H/HI FUSE
H/LOW FUSE
HEAD AUTO
HEAD LAMP RELAY (HI)
HEAD- LAMP RELAY (LOW)
HI LO
HIGH BEAM IND
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT FRONT FOG LAMP
LEFT HEAD- LAMP
LIGHT SWITCH HEAD PARK PARK OFF OFF AUTO
LO HI
MULTI- FUNCTION SWITCH
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RIGHT FRONT FOG LAMP
RIGHT HEAD- LAMP
TAIL LAMP RELAY
TAIL LAMP RLY AUTO CUT CTRL IN
TAIL LAMP RLY AUTO CUT CTRL OUT
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlights circuit, with drl (2 of 2) -> DIMMER/ PASSING SWITCH LOW HIGH FLASH
