Kia Sorento I facelift (2006-2011) backup lamp rly wiring diagram
This page shows the only wiring diagram for the component.backup lamp rly, which is found in the car Kia Sorento I facelift (2006-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
backup lamp rly wiring diagram (1 of 1)
AUTO MODULE (ON RIGHT SIDE OF TRANSMISSION)
BACK WARNING CONTROL MODULE (BEHIND LEFT QUARTERPANEL)
BACKUP LAMP RELAY
BACKUP LAMP RLY
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
EEP ROM BOX ASSEMBLY
GRN WIRE
HOME LINK CONNECTOR
HOT IN ON OR START
I/P JUNCTION BOX (BEHIND LEFT KICK PANEL)
I/P-A
LEFT REAR COMBINATION LAMP LEFT BACKUP LAMP
METER FUSE
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RELAY BOX (BEHIND RIGHT END OF DASH)
RIGHT REAR RIGHT COMBINATION BACKUP LAMP LAMP
SW 1
SW 2
SW 4
TCM (UNDER RIGHT SIDE OF DASH)
TRANSAXLE RANGE SWITCH
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Backup lamps circuit -> BACKUP LAMP RLY
