Kia Sorento I facelift (2006-2011) back warning sens wiring diagram
This page shows the only wiring diagram for the component.back warning sens, which is found in the car Kia Sorento I facelift (2006-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
back warning sens wiring diagram (1 of 1)
4 1 2 3 RX TX
BACK WARNING BUZZER (BEHIND CENTER OF DASH)
BACK WARNING CONTROL MODULE (BEHIND LEFT QUARTERPANEL)
BACK WARNING SENS
BACK-UP GND
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BUZZER
GRN WIRE
HOT AT ALL TIMES
I/P JUNCTION BOX (BEHIND LEFT KICK PANEL)
I/P-A
LEFT BACK WARNING SENSOR (BEHIND LEFT SIDE OF REAR BUMPER)
LEFT SIDE BACK WARNING SENSOR (BEHIND LEFT END OF REAR BUMPER)
NCA WIRE
ORG/ WIRE
RED BLK/ORG WIRE
RED WIRE
RIGHT BACK WARNING SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER)
RIGHT SIDE BACK WARNING SENSOR (BEHIND RIGHT END OF REAR BUMPER)
ROOM FUSE
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit -> BACK WARNING SENS
