Car Wiring Diagrams for Heated seats circuit for Kia Sorento I (2002-2006)

BLK WIRE BLU WIRE DRIVER SEAT WARMER, POWER SEAT (IN DRIVER'S SEAT) F/WIPER FUSE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE HOT AT ALL TIMES HOT IN ON INTEGRATED CONTROL MODULE (BEHIND LEFT KICK PANEL) J/C 14 JB-12 JB-15 JC-20 JC-21 JOINT CONNECTOR P-10 LEFT SEAT WARMER RELAY LEFT SEAT WARMER SWITCH RED WIRE RELAY BLOCK (BEHIND RIGHT END OF DASH) RIGHT SEAT WARMER (IN RIGHT FRONT SEAT) RIGHT SEAT WARMER RELAY RIGHT SEAT WARMER SWITCH S/WARM FUSE SC-02 SC-09 SEAT HEATER WHT WIRE
