Car Wiring Diagrams for Power door locks circuit for Kia Sorento I (2002-2006)

BACK DOOR LOCK MOTOR (IN BACK DOOR) BACK DOOR SWITCH (ON REAR DOOR) BLK WIRE BLU WIRE BLU/BLK WIRE DOOR LOCK FUSE DOOR LOCK RELAY DOOR UNLOCK RELAY ETACS (BELOW CENTER OF DASH) FRONT DOOR) GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES I-01 I-02 INTEGRATED CONTROL MODULE (BEHIND LEFT KICK PANEL) JB-12 JB-15 JC-01 JC-02 JC-23 KEY CYLINDER SWITCH (IN DRIVER'S DOOR) LEFT FRONT DOOR LOCK MOTOR (IN LEFT LEFT REAR DOOR LOCK MOTOR (IN LEFT REAR DOOR) ORG/ WIRE REAR DOOR) RED WIRE RELAY BLOCK (BEHIND RIGHT END OF DASH) RIGHT FRONT DOOR LOCK MOTOR (IN RIGHT RIGHT REAR DOOR LOCK MOTOR (IN RIGHT SC-01 SC-05 TAILGATE KEY SWITCH (ON REAR DOOR) WHT WIRE YEL WIRE
