Kia Sorento I (2002-2006) tns head auto off Wiring diagrams

This page contains all the electrical diagrams for the component. tns head auto off, in which he is found in the car Kia Sorento I (2002-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram tns head auto off (1 of 2)

Wiring diagram tns head auto off for Kia Sorento I (2002-2006)

Get access

ALTERNATOR (RIGHT FRONT OF ENGINE) BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE COMBINATION SWITCH DIODE 1 (BEHIND LEFT SIDE OF DASH) DIODE 2 (BEHIND LEFT END OF DASH) ENGINE ROOM FUSE BOX (AT LEFT SIDE OF ENGINE COMPT) ETACS (BELOW CENTER OF DASH) F/WIPER FUSE GRN WIRE GRN/ORG WIRE HEAD HIGH FUSE HEAD LOW FUSE HEAD TNS AUTO OFF HEAD- LIGHT RELAY (HIGH) HEADLIGHT RELAY (LOW) HOT AT ALL TIMES HOT IN ON J/C 1 JB-05 JB-06 JB-09 JB-12 JB-13 LEFT HEADLAMP LO HI PASS LO PASS ORG/ WIRE RED WIRE RED/BLK WIRE RELAY BLOCK (BEHIND RIGHT END OF DASH) RIGHT HEADLAMP RLY COIL FUSE SC-01 SC-02 SC-08 TNS HEAD AUTO OFF W/ AUTO LIGHT WHT WIRE YEL WIRE

Go to component: -> Headlights circuit, with drl (2 of 2) -> TNS HEAD AUTO OFF

Wiring diagram tns head auto off (2 of 2)

Wiring diagram tns head auto off for Kia Sorento I (2002-2006)

Get access

BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE COMBINATION SWITCH DIODE 1 (BEHIND LEFT SIDE OF DASH) DIODE 2 (BEHIND LEFT END OF DASH) ENGINE ROOM FUSE BOX (AT LEFT SIDE OF ENGINE COMPT) ETACS (BELOW CENTER OF DASH) F/WIPER FUSE GRN WIRE GRN/ORG WIRE HEAD HIGH FUSE HEAD LOW FUSE HEAD- LIGHT RELAY (HIGH) HEADLIGHT RELAY (LOW) HOT AT ALL TIMES HOT IN ON J/C 1 JB-05 JB-06 JB-09 JB-12 JB-13 LEFT HEADLAMP LO HEAD HI PASS LO PASS ORG/ WIRE RED WIRE RED/BLK WIRE RELAY BLOCK (BEHIND RIGHT END OF DASH) RIGHT HEADLAMP RLY COIL FUSE SC-01 SC-02 TNS AUTO OFF TNS HEAD AUTO OFF W/ AUTO LIGHT WHT WIRE YEL WIRE

Go to component: -> Headlights circuit, without drl (2 of 2) -> TNS HEAD AUTO OFF
