Kia Sorento I (2002-2006) right left premium premium tweeter tweeter speaker speaker wiring diagram
This page shows the only wiring diagram for the component.right left premium premium tweeter tweeter speaker speaker, which is found in the car Kia Sorento I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right left premium premium tweeter tweeter speaker speaker wiring diagram (1 of 1)
2 J-09
2 J-18
AMPLIFIER
ANTENNA
AUDIO REMOTE CONTROL SWITCH
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
CLOCKSPRING/ STEERING REMOTE CONTROL SWITCH
DRIVER PREMIUM SPEAKER
FUSE
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM FUSE BOX (AT LEFT SIDE OF ENGINE COMPT) AUDIO FUSE
HOT IN ACC OR ON
JB-05
JB-13
JB-15
JC-01
LEFT REAR DOOR SPEAKER
LT GRN WIRE
NCA WIRE
PASSENGER PREMIUM SPEAKER
PREMIUM AUDIO FUSE
PREMIUM AUDIO UNIT (CENTER OF DASH)
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RELAY BLOCK (BEHIND RIGHT END OF DASH)
RIGHT LEFT PREMIUM PREMIUM TWEETER TWEETER SPEAKER SPEAKER
RIGHT REAR DOOR SPEAKER
SC-04
SC-08
SC-10
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Premium sound radio circuit -> RIGHT LEFT PREMIUM PREMIUM TWEETER TWEETER SPEAKER SPEAKER
