Kia Sorento I (2002-2006) right front door speaker Wiring diagram
This page shows the only wiring diagram for the component.right front door speaker, which is found in the car Kia Sorento I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front door speaker (1 of 1)
ANTENNA
AUDIO FUSE
AUDIO REMOTE CONTROL SWITCH
AUDIO UNIT (CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
ENGINE ROOM FUSE BOX (AT LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON RELAY BLOCK (BEHIND RIGHT END OF DASH)
J-09 CLOCKSPRING/ STEERING REMOTE CONTROL SWITCH
J-18
J/C 1
JB-05
JB-15
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT TWEETER SPEAKER
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER SPEAKER
SHORT CONNECTOR SC-04
SHORT CONNECTOR SC-08
SHORT CONNECTOR SC-10
YEL WIRE
Go to component: -> Base model circuit -> RIGHT FRONT DOOR SPEAKER
