Kia Sorento I (2002-2006) rear marker lamp turn lamp Wiring diagram
This page shows the only wiring diagram for the component.rear marker lamp turn lamp, which is found in the car Kia Sorento I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear marker lamp turn lamp (1 of 1)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
COMBINATION SWITCH
ENGINE ROOM FUSE BOX (AT LEFT SIDE OF ENGINE COMPT)
ETACS (BELOW CENTER OF DASH)
EXT FUSE (W/O DRL)
FLASHER UNIT (BEHIND LEFT SIDE OF DASH)
HAZARD RELAY (IN RELAY BLOCK)
HAZARD SWITCH
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT AT ALL TIMES RELAY BLOCK (BEHIND RIGHT END OF DASH) HAZARD FUSE
HOT IN ON OR START
INSTRUMENT CLUSTER
JB-05
JB-06
JB-08
JB-13
JB-15
JC-01
JC-02
JC-20
JC-21
JC-21 (BEHIND RIGHT TAILLIGHT ASSEMBLY)
JC-23
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN LAMP LEFT FRONT COMBINATION LAMP
LEFT POSITION LAMP
LEFT SIDE TURN LAMP
LEFT TURN INDICATOR
MEMORY FUSE
ORG/ WIRE
REAR MARKER LAMP TAIL LAMP
REAR MARKER LAMP TURN LAMP
RED WIRE
RED/BLK WIRE
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN LAMP RIGHT FRONT COMBINATION LAMP
RIGHT LICENSE LEFT LICENSE HIGH MOUNT LIGHT LIGHT STOPLIGHT
RIGHT POSITION LAMP
RIGHT REAR COMBINATION LAMP
RIGHT SIDE TURN LAMP
RIGHT TURN INDICATOR
SC-01
SC-03 SC-05
SC-04
SC-06
SC-08
SC-09
SC-11
SC-14
SC-15
STOP FUSE
STOP LAMP
STOP LAMP TURN LAMP
STOP LIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
TAIL LAMP
TNS OFF HEAD TR
TNS RELAY
TRAILER LAMP CONNECTOR
TURN FUSE
WHT WIRE
YEL WIRE
Go to component: -> Exterior lamps circuit -> REAR MARKER LAMP TURN LAMP
