Kia Sorento I (2002-2006) panel light tccs control relay switch wiring diagram
This page shows the only wiring diagram for the component.panel light tccs control relay switch, which is found in the car Kia Sorento I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
panel light tccs control relay switch wiring diagram (1 of 1)
ABS CONTROL UNIT
AIR CON CONTROL EPS UNIT UNIT
AIR CON CONTROL POWER UNIT TRANSISTOR
AUTO CRUISE FRONT REAR CONTROL DEFROSTER DEFROSTER MAIN SWITCH SWITCH SWITCH
AUTO LIGHT UNIT
BACK GLASS OPENER SWITCH
BLK WIRE
CLUTCH INTER LOCK SWITCH
CONDENSER FAN 2 RELAY
DATA LINK CONNECTOR
DIGITAL CLOCK
DRL UNIT ETACS
ENGINE ROOM FUSE BOX
FLASHER UNIT
FROM SHORT CONNECTOR JC-01 (DIAGRAM 1 OF 3)
FRONT CIGAR LIGHTER ILLUMINATION
GLOVE REAR FRONT BOX CIGAR POWER ILLUMINATION LIGHTER OUTLET
HIGH BLOWER RELAY
IMMOBILIZER UNIT
INSTRUMENT CLUSTER
JB-09
JB-13
KEY CYLINDER SWITCH
LEFT FRONT DOOR LOCK MOTOR
LEFT MIRROR DEFROSTER
LEFT SEAT WARMER SWITCH
MODE ACTUATOR
OBD-II CHECK CONNECTOR
PANEL LIGHT TCCS CONTROL RELAY SWITCH
POWER MIRROR SWITCH
POWER WINDOW MAIN SWITCH
PREMIUM AUDIO
REAR CONDENSER POWER FAN OUTLET MOTOR
REAR WIPER CONTROL UNIT AUDIO
RELAY BLOCK CIGAR POWER LIGHTER OUTLET RELAY RELAY
RIGHT SEAT WARMER ETACS SWITCH
SHORT CONNECTOR JC-01
SHORT CONNECTOR JC-13
SHORT CONNECTOR JC-14
SIDE OF ENGINE COMPT)
TOD SWITCH
W/ EST
W/ TOD
Go to component -> Ground distribution circuit (2 of 3) -> PANEL LIGHT TCCS CONTROL RELAY SWITCH
