Kia Sorento I (2002-2006) left front door lock motor (in left Wiring diagram
This page shows the only wiring diagram for the component.left front door lock motor (in left, which is found in the car Kia Sorento I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door lock motor (in left (1 of 1)
BACK DOOR LOCK MOTOR (IN BACK DOOR)
BACK DOOR SWITCH (ON REAR DOOR)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
DOOR LOCK FUSE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
ETACS (BELOW CENTER OF DASH)
FRONT DOOR)
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
I-01
I-02
INTEGRATED CONTROL MODULE (BEHIND LEFT KICK PANEL)
JB-12
JB-15
JC-01
JC-02
JC-23
KEY CYLINDER SWITCH (IN DRIVER'S DOOR)
LEFT FRONT DOOR LOCK MOTOR (IN LEFT
LEFT REAR DOOR LOCK MOTOR (IN LEFT REAR DOOR)
ORG/ WIRE
REAR DOOR)
RED WIRE
RELAY BLOCK (BEHIND RIGHT END OF DASH)
RIGHT FRONT DOOR LOCK MOTOR (IN RIGHT
RIGHT REAR DOOR LOCK MOTOR (IN RIGHT
SC-01
SC-05
TAILGATE KEY SWITCH (ON REAR DOOR)
WHT WIRE
YEL WIRE
Go to component: -> Power door locks circuit -> LEFT FRONT DOOR LOCK MOTOR (IN LEFT
