Kia Sorento I (2002-2006) joint connector p-10 Wiring diagrams

This page contains all the electrical diagrams for the component. joint connector p-10, in which he is found in the car Kia Sorento I (2002-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram joint connector p-10 (1 of 2)

Wiring diagram joint connector p-10 for Kia Sorento I (2002-2006)

Get access

BLK WIRE BLU WIRE DRIVER SEAT WARMER, POWER SEAT (IN DRIVER'S SEAT) F/WIPER FUSE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE HOT AT ALL TIMES HOT IN ON INTEGRATED CONTROL MODULE (BEHIND LEFT KICK PANEL) J/C 14 JB-12 JB-15 JC-20 JC-21 JOINT CONNECTOR P-10 LEFT SEAT WARMER RELAY LEFT SEAT WARMER SWITCH RED WIRE RELAY BLOCK (BEHIND RIGHT END OF DASH) RIGHT SEAT WARMER (IN RIGHT FRONT SEAT) RIGHT SEAT WARMER RELAY RIGHT SEAT WARMER SWITCH S/WARM FUSE SC-02 SC-09 SEAT HEATER WHT WIRE

Go to component: -> Heated seats circuit -> JOINT CONNECTOR P-10

Wiring diagram joint connector p-10 (2 of 2)

Wiring diagram joint connector p-10 for Kia Sorento I (2002-2006)

Get access

BLK WIRE BLU WIRE ETACS FRONT LIFT REAR LIFT MOTOR MOTOR GRN WIRE HEATED SEATS CIRCUIT HOT AT ALL TIMES JB-11 JOINT CONNECTOR JC-20 JOINT CONNECTOR P-10 LT GRN WIRE ORG/ WIRE P/SEAT FUSE (PASSENGER) POWER SEAT SWITCH RECLINE MOTOR RED WIRE RELAY BLOCK (BEHIND RIGHT END OF DASH) SEAT BELT SWITCH SEAT HEATER SLIDE MOTOR WHT WIRE YEL WIRE

Go to component: -> Power seats circuit -> JOINT CONNECTOR P-10
