Kia Sorento I (2002-2006) joint connector jc-20 Wiring diagram

This page shows the only wiring diagram for the component.joint connector jc-20, which is found in the car Kia Sorento I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram joint connector jc-20 (1 of 1)

Wiring diagram joint connector jc-20 for Kia Sorento I (2002-2006)

Get access

BLK WIRE BLU WIRE ETACS FRONT LIFT REAR LIFT MOTOR MOTOR GRN WIRE HEATED SEATS CIRCUIT HOT AT ALL TIMES JB-11 JOINT CONNECTOR JC-20 JOINT CONNECTOR P-10 LT GRN WIRE ORG/ WIRE P/SEAT FUSE (PASSENGER) POWER SEAT SWITCH RECLINE MOTOR RED WIRE RELAY BLOCK (BEHIND RIGHT END OF DASH) SEAT BELT SWITCH SEAT HEATER SLIDE MOTOR WHT WIRE YEL WIRE

Go to component: -> Power seats circuit -> JOINT CONNECTOR JC-20
