Kia Sorento I (2002-2006) back glass opener relay Wiring diagrams
This page contains all the electrical diagrams for the component. back glass opener relay, in which he is found in the car Kia Sorento I (2002-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
back glass opener relay wiring diagram (1 of 2)
BACK GLASS ACTUATOR (AT LOWER CENTER OF BACK DOOR)
BACK GLASS OPENER RELAY
BACK GLASS OPENER SWITCH
BLK WIRE
BLU WIRE
BLU/ORG WIRE
D/LOCK FUSE
ETACS (BELOW CENTER OF DASH)
HOT AT ALL TIMES
INTEGRATED CONTROL MODULE (BEHIND LEFT KICK PANEL)
JB-12
JC-01
ORG/ WIRE
RED/BLK WIRE
RED/ORG WIRE
RELAY BLOCK (BEHIND RIGHT END OF DASH)
SC-01
SHORT CONNECTOR JC-23
WIPER/WASHER SYSTEM
Go to component -> Liftglass release circuit -> BACK GLASS OPENER RELAY
back glass opener relay wiring diagram (2 of 2)
AMPLIFIER
BACK GLASS OPENER RELAY
BLU WIRE
BLU/BLK WIRE
BTN 2 FUSE
BTN 3 FUSE
D/LOCK FUSE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER'S POWER SEAT, SEAT WARMER
ETACS
F/BLOWER FUSE
FROM F/FOG
FRONT BLOWER RELAY
FRONT DEFROSTER RELAY
FUSE
HAZARD FUSE
HAZARD SWITCH HAZARD RELAY
HEADLIGHT RELAY (HIGH)
HEADLIGHT RELAY (LOW)
INTEGRATED CONTROL MODULE (BEHIND LEFT KICK PANEL)
JB-04
JB-07
JB-11
JB-12
JB-13
JB-14
JB-15
LEFT SEAT WARMER RELAY
OBD-II CHECK CONNECTOR
ORG/ WIRE
PREMIUM AUDIO FUSE
RED WIRE
RELAY BLOCK (BEHIND RIGHT END OF DASH)
RIGHT SEAT WARMER RELAY
S/ROOF FUSE
S/WARM FUSE
SC-01
SUN ROOF UNIT
TNS RELAY
TO AUDIO
TO CIGAR LIGHTER RELAY (DIAGRAM 5 OF 5)
W/SHD FUSE P/SEAT FUSE
WHT WIRE
Go to component -> Power distribution circuit (3 of 5) -> BACK GLASS OPENER RELAY
