Kia Sorento I (2002-2006) audio transaxle clutch cruise cut range control switch switch unit Wiring diagram
This page shows the only wiring diagram for the component.audio transaxle clutch cruise cut range control switch switch unit, which is found in the car Kia Sorento I (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram audio transaxle clutch cruise cut range control switch switch unit (1 of 1)
A/T M/T
AIR INSTRUMENT CON CLUSTER CONTROL UNIT
AUDIO
AUDIO FUSE
AUDIO TRANSAXLE CLUTCH CRUISE CUT RANGE CONTROL SWITCH SWITCH UNIT
BLU WIRE
BTN 1 FUSE
CARGO ROOM LAMP
CENTER ROOM LAMP
DATA LINK CONNECTOR
ECM HOME LINK
ENGINE ROOM FUSE BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE TRANSFER CASE CONTROL CONTROL UNIT MODULE
ETACS
FROM BNT 2
FUSE
GRN WIRE
HAZARD DIGITAL RELAY CLOCK
IMMOBILIZER UNIT
JB-05
JB-06
JB-07
JB-12 JB-12
JB-13
JB-14
JB-15
KEY REMAIN SWITCH
LEFT FRONT DOOR COURTESY LAMP
LEFT REAR DOOR COURTESY LAMP
LEFT SUNVISOR LAMP FROM IGNITION SWITCH (DIAGRAM 1 OF 5)
MEMORY FUSE
MULTI- METER
OVERHEAD CONSOLE
REAR WIPER CONTROL UNIT
RED WIRE
RIGHT FRONT DOOR COURTESY LAMP
RIGHT REAR DOOR COURTESY LAMP
RIGHT SUNVISOR LAMP
ROOM FUSE
SC-04
SC-06
SC-08
SC-10
STOP FUSE
STOPLIGHT SWITCH
TCCS FUSE
TO POWER OUTLET RELAY (DIAGRAM 5 OF 5)
TOD EST
TRANSAXLE CONTROL MODULE
YEL WIRE
Go to component: -> Power distribution circuit (4 of 5) -> AUDIO TRANSAXLE CLUTCH CRUISE CUT RANGE CONTROL SWITCH SWITCH UNIT
