Kia Sorento I (2002-2006) air con relay Wiring diagrams
This page contains all the electrical diagrams for the component. air con relay, in which he is found in the car Kia Sorento I (2002-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram air con relay (1 of 3)
AIR CON RELAY
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
C/FAN 1 FUSE
C/FAN 2 FUSE
COMPRESSOR)
CONDENSER FAN 2 RELAY
CONDENSER FAN HIGH RELAY
CONDENSER FAN LOW RELAY
CONDENSER FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN MOTOR (FRONT RIGHT OF ENGINE COMPT)
DATA LINK CONNECTOR (AT LEFT REAR OF ENGINE COMPT)
ECU FUSE
ENGINE COOLANT TEMPERATURE SENSOR (TOP FRONT OF ENGINE)
ENGINE ROOM FUSE BOX (AT LEFT SIDE OF ENGINE COMPT)
FROM BLOWER RELAY (DIAGRAM 1 OF 2)
GRN/BLK WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
INJ FUSE
JB-02
JB-03
JB-06
JB-08
JB-09
JB-15
MAIN RELAY
MEMORY FUSE
METER FUSE
P/TRN FUSE
RED WIRE
RED/BLK WIRE
RELAY BLOCK (BEHIND RIGHT END OF DASH)
SC-08
SC-09
SC-10
SC-12
WHT WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> AIR CON RELAY
Wiring diagram air con relay (2 of 3)
AIR CON RELAY
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
C/FAN 1 FUSE
C/FAN 2 FUSE
COMPRESSOR)
CONDENSER FAN 2 RELAY
CONDENSER FAN HIGH RELAY
CONDENSER FAN LOW RELAY
CONDENSER FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN MOTOR (FRONT RIGHT OF ENGINE COMPT)
DATA LINK CONNECTOR (AT LEFT REAR OF ENGINE COMPT)
ECU FUSE
ENGINE COOLANT TEMPERATURE SENSOR (TOP FRONT OF ENGINE)
ENGINE ROOM FUSE BOX (AT LEFT SIDE OF ENGINE COMPT)
FROM BLOWER RELAY (DIAGRAM 1 OF 2)
GRN/BLK WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
INJ FUSE
JB-02
JB-03
JB-06
JB-08
JB-09
JB-15
MAIN RELAY
MEMORY FUSE
METER FUSE
P/TRN FUSE
RED WIRE
RED/BLK WIRE
RELAY BLOCK (BEHIND RIGHT END OF DASH)
SC-08
SC-09
SC-10
SC-12
WHT WIRE
Go to component -> Manual a/c circuit (2 of 2) -> AIR CON RELAY
Wiring diagram air con relay (3 of 3)
A/BAG FUSE
ABS CONTROL UNIT
AIR BAG CONTROL UNIT
AIR CON CONTROL UNIT
AIR CON RELAY
AUTO CRUISE CONTROL MAIN SWITCH
AUTO CRUISE CONTROL UNIT
BACK-UP TRANSAXLE RANGE LIGHT SWITCH SWITCH
BLK WIRE
BLU WIRE
C/FAN 1 FUSE
C/FAN 2 FUSE
CONDENSER FAN HIGH RELAY
CONDENSER FAN LOW RELAY
DATA LINK CONNECTOR
DEF FUSE
ENG FUSE
ENGINE CONTROL MODULE
ENGINE ROOM FUSE BOX (AT LEFT SIDE OF ENGINE COMPT)
EPS UNIT
EST TOD
ETACS
FROM HORN
FROM IGNITION SWITCH (DIAGRAM 1 OF 5)
FRONT FOGLAMP RELAY
FUEL PUMP RELAY
HAZARD AUTO SWITCH LIGHT UNIT
IGNITION FAILURE SENSOR
IMMOBILIZER DRL UNIT UNIT
JB-02
JB-03
JB-05
JB-12
JB-13
JB-15
JB-16
METER FUSE
MULTI- ECM METER HOME LINK
ORG/ WIRE
REAR DEFROSTER RELAY
RED WIRE
RELAY BLOCK (BEHIND RIGHT END OF DASH)
SC-01
SC-04
SC-09
SC-10
SC-13
SPEED SENSOR
STEERING REMOCON SWITCH
STOPLIGHT SWITCH
TO BTN 3
TRAILER FUSE
TRANSAXLE TRAILER CONTROL LAMP MODULE
TRANSFER CASE CONTROL UNIT
TURN FUSE
YEL WIRE
Go to component -> Power distribution circuit (2 of 5) -> AIR CON RELAY
