Kia Sorento Prime III facelift (2017-2020) surround view monitoring unit shield Wiring diagram
This page shows the only wiring diagram for the component.surround view monitoring unit shield, which is found in the car Kia Sorento Prime III facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram surround view monitoring unit shield (1 of 1)
3.3L
A/V, NAVIGATION HEAD UNIT
A/V, NAVIGATION HEAD UNIT SHIELD
AUDIO
AUX JACK
AUX, USB JACK
BATTERY
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLK/ORG WIRE
BLOWER RELAY
BRAKE FLUID LEVEL SENSOR
BURGLAR ALARM HORN
COLUMN TYPE
COOLING FAN 1 RELAY
COOLING FAN CONTROLLER
E/R-A
E/R-B
ESC MODULE
EXTERNAL BUZZER
FRONT DEICER
FRONT FOG LAMP (LED) OPT
FRONT WIPER MOTOR
HID OPT GROUND
I/P-B
IDB (INJECTOR DRIVER BOX)
IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE)
LEFT FRONT FOG LAMP
MDPS UNIT
MIC SHIELD
MULTI-PURPOSE CHECK CONNECTOR
NCA WIRE
PCB BLOCK
PDM (ACC) RELAY
POWER OUTLET RELAY
RIGHT FRONT FOG LAMP
SURROUND VIEW MONITORING UNIT
SURROUND VIEW MONITORING UNIT SHIELD
W/ DISPLAY
W/ NAVIGATION
W/ SMART KEY
W/ SURROUND VIEW
W/O DISPLAY
W/O LED W/ LED
W/O NAVIGATION
WASHER LEVEL SENSOR
WIPER HI RELAY
WIPER LO RELAY
Go to component -> Ground distribution circuit (2 of 6) -> SURROUND VIEW MONITORING UNIT SHIELD
