Kia Sorento Prime III facelift (2017-2020) passenger occupant detection sensor Wiring diagram
This page shows the only wiring diagram for the component.passenger occupant detection sensor, which is found in the car Kia Sorento Prime III facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger occupant detection sensor (1 of 1)
AUTO HEADLAMP LEVELING DEVICE MODULE
BLK WIRE
BLU WIRE
BODY K-LINE
BRN WIRE
BRN/ORG WIRE
C-CAN HIGH
C-CAN LOW
ELECTRIC PARKING BRAKE MODULE
FUEL PUMP CONTROL MODULE
GRN WIRE
IMMOBILIZER MODULE
LANE DEPARTURE WARNING MODULE
LEFT "C" PILLAR)
LEFT BLIND SPOT DETECTION RADAR (BEHIND LEFT END OF REAR BUMPER FASCIA)
MDPS UNIT (RACK TYPE) (ON STEERING RACK ASSEMBLY)
NCA WIRE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PASSENGER OCCUPANT DETECTION SENSOR
PRIVATE HIGH
PRIVATE LOW
REAR VIEW CAMERA (BOTTOM CENTER TAILGATE)
RIGHT BLIND SPOT DETECTION RADAR (BEHIND RIGHT END OF REAR BUMPER FASCIA)
SMART CRUISE CONTROL RADAR
SRS CONTROL MODULE
TIRE PRESSURE MONITORING MODULE
VEH SPD I/P
W/ AUTO CRUISE/ RACK TYPE
W/ LDWS
W/ RVC/TPMS/EPB/ BSD/SVMS
W/O AUTO CRUISE/ RACK TYPE
W/O LDWS
W/O RVC/TPMS/EPB/ BSD/SVMS
W/O SMART KEY
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (2 of 3) -> PASSENGER OCCUPANT DETECTION SENSOR
