Kia Sorento Prime III facelift (2017-2020) float empty Wiring diagram
This page shows the only wiring diagram for the component.float empty, which is found in the car Kia Sorento Prime III facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram float empty (1 of 1)
A/C PRESSURE TRANSDUCER
ACCEL PEDAL POSITION SENSOR
B(+)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN TRANSCEIVER
CHECK ENGINE IND
COMPUTER DATA LINES SYSTEM
FLOAT EMPTY
FPS GND
FPS IN
FPS SUPPLY
FUEL FUEL LEVEL
FUEL PRESSURE SENSOR
FUEL SENDER FUEL PUMP CONTROL MODULE
FUEL TANK PRESSURE SENSOR
GND SIG 1
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
MICOM
NCA WIRE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PNK WIRE
RAIL PRESSURE SENSOR
SIG
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.3l (2 of 9) -> FLOAT EMPTY
