Kia Sorento Prime III facelift (2017-2020) drv front height adj sw up Wiring diagram
This page shows the only wiring diagram for the component.drv front height adj sw up, which is found in the car Kia Sorento Prime III facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv front height adj sw up (1 of 1)
B-CAN
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BWD
COMPUTER DATA LINES SYSTEM
DRIVER CUSHION MOTOR
DRIVER DOOR MODULE
DRIVER LUMBAR SUPPORT MOTOR (FWD/BWD)
DRIVER LUMBAR SUPPORT MOTOR (UP/DOWN)
DRIVER RECLINING LIMIT SWITCH
DRIVER SEAT MANUAL SWITCH
DRV CUSHION MTR DOWN
DRV CUSHION MTR UP
DRV FRONT HEIGHT ADJ SW DOWN
DRV FRONT HEIGHT ADJ SW UP
DRV LUMBAR SUPPORT MTR BWD
DRV LUMBAR SUPPORT MTR DOWN
DRV LUMBAR SUPPORT MTR FWD
DRV LUMBAR SUPPORT MTR UP
DRV REAR HEIGHT ADJ SW DOWN
DRV REAR HEIGHT ADJ SW UP
DRV RECLINING SW BWD
DRV RECLINING SW FWD
DRV SLIDE SW BWD
DRV SLIDE SW FWD
GRN WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
GRY/ORG WIRE
HOT IN ON OR START
I/P-C
IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE)
ILL
IMS SWITCH
MEMORY PWR
MODULE 1 FUSE
ORG/ WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
S GND
SET-
TRANSCEIVER IC
WHT/ORG WIRE
YEL WIRE
Go to component -> Memory seat circuit (2 of 2) -> DRV FRONT HEIGHT ADJ SW UP
