Climate control seats circuit for Kia Sorento Prime III (2014-2017)

BLK WIRE BLOWER PWR BLU WIRE BLU/WHT WIRE BRN WIRE CCS HIGH IND CCS MID IND CCS SW SIG CCS SWITCH CUSHION SNS DETENT DRIVER CCS CONTROL MODULE DRIVER CCS CUSHION BLOWER MOTOR DRIVER CCS CUSHION WARMER DRIVER CCS RECLINING BLOWER MOTOR DRIVER CCS RECLINING WARMER GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY WIRE HEATER CUSHION HEATER HIGH IND HEATER HIGH IND SWITCH HEATER LOW IND HEATER MID IND HEATER PWR HEATER SW SIG HIGH IND HOT AT ALL TIMES HOT IN ON HOT IN ON OR START I/P-A I/P-C I/P-D ILL JOINT CONNECTOR UMD LEAK CURRENT AUTOCUT DEVICE LEFT FRONT CCS SWITCH LOW IND LT GRN WIRE MEMORY FUSE MEMORY PWR MID IND MID IND LOW IND MODULE 3 FUSE MODULE 5 FUSE MOTOR CTRL NCA WIRE ON INPUT ON/START INPUT ORG/ WIRE ORG/BLK WIRE ORG/RED WIRE PNK CCS LOW IND WIRE PNK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/ORG WIRE S/HEATER FRT FUSE SMART JUNCTION BOX WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE

BLK WIRE BLOWER PWR BLU WIRE BLU/WHT WIRE BRN WIRE CCS HIGH IND CCS LOW IND CCS MID IND CCS SWITCH CUSHION SNS DETENT GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY WIRE HEATER CUSHION HEATER HIGH IND HEATER LOW IND HEATER MID IND HEATER PWR HEATER SWITCH HIGH IND ILL LOW IND LT GRN WIRE MEMORY PWR MID IND MOTOR CTRL NCA WIRE ON INPUT ON/START INPUT ORG/ WIRE ORG/BLK WIRE ORG/RED WIRE PASSENGER CCS CONTROL MODULE PASSENGER CCS CUSHION BLOWER MOTOR PASSENGER CCS CUSHION WARMER PASSENGER CCS RECLINING BLOWER MOTOR PASSENGER CCS RECLINING WARMER PNK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/ORG WIRE RIGHT FRONT CCS SWITCH WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE
