Kia Sorento Prime III (2014-2017) up/ down/ right left Wiring diagram
This page shows the only wiring diagram for the component.up/ down/ right left, which is found in the car Kia Sorento Prime III (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram up/ down/ right left (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
BSD LAMP
DEFOGGER
DEFOGGER SYSTEM
DOWN
DRIVER POWER OUTSIDE MIRROR
FOLDING
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR START
I/P-D
LEAK CURRENT AUTOCUT DEVICE
LEFT
LEFT FOLDING MOTOR
LEFT OUTSIDE MIRROR
LEFT RIGHT
MEMORY FUSE
MIRROR FOLDING SWITCH
MODULE 4 FUSE
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
POWER OUTSIDE MIRROR SWITCH
RED WIRE
RIGHT
RIGHT FOLDING MOTOR
RIGHT OUTSIDE MIRROR
SELECTOR SWITCH RIGHT
SMART JUNCTION BOX
TURN LAMP
UNFOLDING
UP DOWN
UP/ DOWN/ RIGHT LEFT
WHT WIRE
Go to component -> Power mirror circuit -> UP/ DOWN/ RIGHT LEFT
