Kia Sorento Prime III (2014-2017) tailgate console sw Wiring diagrams

B-CAN B-CAN HI B-CAN LO BATTERY PWR BLK WIRE BLU WIRE BLU/BLK WIRE CARGO LAMP COMPUTER DATA LINES SYSTEM DOOR DOOR ON E/R FUSE, RELAY BOX GRN WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES I/P-K I/P-M I/P-L IPS CONTROL MODULE JOINT CONNECTOR URA JOINT CONNECTOR URB LATCH GND LEFT MAP LAMP LEFT REAR PERSONAL LAMP LEFT VANITY LAMP LOW HIGH OFF ORG/ WIRE OVERHEAD CONSOLE LAMP P/TAIL GATE FUSE POWER TAILGATE MODULE RED WIRE RIGHT MAP LAMP RIGHT REAR PERSONAL LAMP RIGHT VANITY LAMP ROOM LAMP ROOM LAMP OUTPUT SMART JUNCTION BOX TAIL GATE OPEN SW TAILGATE CONSOLE SW TAILGATE ON/OFF SW TRUNK, TAILGATE, FUEL DOORS SYSTEM W/ POWER TAILGATE W/O POWER TAILGATE W/ SUNROOF W/O SUNROOF WHT WIRE WHT/RED WIRE

B-CAN HIGH B-CAN LOW BATTERY PWR BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BUZZER COMPUTER DATA LINES SYSTEM ENGINE ROOM RELAY BOX GRN WIRE GRN/ORG WIRE GROUND GRY WIRE GRY/BLK WIRE GRY/ORG WIRE HALL SENSOR HOME POS SW HOT AT ALL TIMES ILL INTERIOR SWITCH INTERIOR SWITCH ILL (+) JOINT CONNECTOR URB LATCH GROUND LEFT SPINDLE ACTUATOR (LEFT "D" PILLAR) LEFT TAILGATE PINCH SWITCH LH HALL SNSR 1 LH HALL SNSR 2 LH HALL SNSR GND LH HALL SNSR PWR LH SPINDLE MTR (+) LOCK SW NCA WIRE ORG/ WIRE OVERHEAD CONSOLE LAMP P/TAIL GATE FUSE PINCH STRIP 1 (-) PINCH STRIP 2 (-) PNK WIRE PNK/BLK WIRE PNK/ORG WIRE POWER TAILGATE MODULE (LEFT "D" PILLAR) PTG SW PUC CINCHING (+) PWR SW RED WIRE RED/BLK WIRE RED/ORG WIRE RH HALL SNSR 1 RH HALL SNSR 2 RH HALL SNSR GND RH HALL SNSR PWR RH SPINDLE MTR (+) RIGHT SPINDLE ACTUATOR (RIGHT "D" PILLAR) RIGHT TAILGATE PINCH SWITCH SECONDARY SW SHIELD GND SHIELD GROUND TAILGATE BUZZER TAILGATE CONSOLE SW TAILGATE INNER SWITCH TAILGATE ON/OFF SW WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE
