Kia Sorento Prime III (2014-2017) pass ind gnd Wiring diagram
This page shows the only wiring diagram for the component.pass ind gnd, which is found in the car Kia Sorento Prime III (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass ind gnd (1 of 1)
BLIND SPOT DETECTION SWITCH
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN/BLK WIRE
BSD LAMP
C-CAN
C-CAN HIGH
C-CAN LOW
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DRIVER POWER OUTSIDE MIRROR
DRV IND GND
DRV IND VCC
HOT IN ON OR START
I/P-A
I/P-M
IND
INSTRUMENT CLUSTER
IPS CONTROL MODULE
LEFT BLIND SPOT DETECTION RADAR
MICOM
MODULE 3 FUSE
NCA WIRE
ON/START IN
ORG/ WIRE
ORG/BLK WIRE
PASS IND GND
PASS IND VCC
PASSENGER POWER OUTSIDE MIRROR
PNK/BLK WIRE
RED WIRE
RED/ORG WIRE
RIGHT BLIND SPOT DETECTION RADAR
RIGHT END OF DASH)
SMART JUNCTION BOX
TRANSCEIVER/
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Blind spot information system circuit -> PASS IND GND
