Kia Sorento Prime III (2014-2017) lin data line Wiring diagram
This page shows the only wiring diagram for the component.lin data line, which is found in the car Kia Sorento Prime III (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lin data line (1 of 1)
AL ELE LOAD SIG
ALTER PWM OUT
ANTI-THEFT SYSTEM
BATTERY SENSOR
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRAKE LT SW
BRAKE SWITCH FUSE
BRAKE TEST SW
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CKP GND
CKP SIG
CMPS 1 GND
CMPS 1 INTAKE
CMPS 2 EXHAUST
CMPS 2 GND
COOLIN FAN CTRL
COOLING FANS SYSTEM
E/R FUSE, RELAY BOX
ENG CTRL RLY IN
ESC MODULE
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IMMO IND
INJ CTRL 2 HI
INJ CTRL 2 LO
INJ CTRL 3 HI
INJ CTRL 3 LO
KNOCK SENS SHLD
KNOCK SENS SIG
KNOCK SENSOR
LIN DATA LINE
LIN LINE
MAP SENSOR
ON/ST IN
ORG/ WIRE
PCM
PNK WIRE
PNK/BLK WIRE
POWER GND
RED WIRE
RED/BLK WIRE
SENSOR 3 FUSE
SENSOR 5 FUSE
SNSR
SPD SIG
STARTING/ CHARGING SYSTEM
STOP SIGNAL ELECTRONIC MODULE
TCU FUSE
WHT WIRE
WHT/BLK WIRE
WIPER "P" IN
WIPER/ WASHER SYSTEM
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.4l (4 of 5) -> LIN DATA LINE
