Kia Sorento Prime III (2014-2017) eng ctrl on Wiring diagram
This page shows the only wiring diagram for the component.eng ctrl on, which is found in the car Kia Sorento Prime III (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eng ctrl on (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
CCP-CAN HIGH
CCP-CAN LOW
COMPUTER DATA
E/R FUSE, RELAY BOX
ENG CTRL ON
FUEL PRE HI
FUEL PRE LO
FUEL PRESSURE
FUEL PRESSURE REGULATOR VALVE
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
HOT IN ON OR START
IDB (INJECTOR DRIVER BOX)
INJ 1 HI
INJ 1 LO
INJ 2 HI
INJ 3 HI
INJ 4 HI
INJ 4 LO
INJ 5 HI
INJ CTRL 2 LO
INJ CTRL 3 LO
INJ CTRL 5 LO
INJ CTRL 6 HI
INJ CTRL 6 LO
INJ INPUT 1
INJ INPUT 2
INJ INPUT 3
INJ INPUT 4
INJ INPUT 5
INJ INPUT 6
INJECTORS
LINES SYSTEM
MEM PWR
NCA WIRE
ON/STRT I/P
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
TCU FUSE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.3l (4 of 8) -> ENG CTRL ON
