Kia Sorento Prime III (2014-2017) driver reclining limit motor Wiring diagram
This page shows the only wiring diagram for the component.driver reclining limit motor, which is found in the car Kia Sorento Prime III (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver reclining limit motor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BWD
DRIVER FRONT HEIGHT ADJUSTER MOTOR
DRIVER FRONT HEIGHT ADJUSTER SWITCH
DRIVER LUMBAR SUPPORT MOTOR
DRIVER LUMBAR SUPPORT SWITCH
DRIVER REAR HEIGHT ADJUSTER MOTOR
DRIVER REAR HEIGHT ADJUSTER SWITCH
DRIVER RECLINING LIMIT MOTOR
DRIVER RECLINING SWITCH
DRIVER SEAT MANUAL SWITCH
DRIVER SLIDE MOTOR
DRIVER SLIDE SWITCH
DRV P/SEAT FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
I/P-A
NCA WIRE
RED WIRE
SMART JUNCTION BOX
WHT WIRE
YEL WIRE
Go to component -> Lumbar circuit, w/ power seats -> DRIVER RECLINING LIMIT MOTOR
