Kia Sorento Prime III (2014-2017) compass control button Wiring diagram
This page shows the only wiring diagram for the component.compass control button, which is found in the car Kia Sorento Prime III (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram compass control button (1 of 1)
BACKUP
BLK WIRE
BRN WIRE
COMPASS CONTROL BUTTON
DIMMING ON/OFF SWITCH
EC MIRROR CONTROL
ELECTROCHROMIC MIRROR
HL 1
HL 2 HL 3
HOME LINK
HOT AT ALL TIMES
HOT IN ON
I/P-C
I/P-E
INDICATOR
INPUT
JOINT CONNECTOR UMB
JOINT CONNECTOR URB
LEAK CURRENT AUTOCUT DEVICE
MEMORY
MEMORY FUSE
MODULE 5 FUSE
PNK WIRE
POWER
SIGNAL
SMART JUNCTION BOX
YEL/ORG WIRE
Go to component -> Electrochromic mirror circuit -> COMPASS CONTROL BUTTON
