Cruise control circuit for Kia Sephia II (1997-2001)

1 2 3 4 5 6 7 8 9 10 B+ BRAKE SW INPUT A/T BLK WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRAKE PEDAL SWITCH (BELOW LEFT SIDE OF DASH) BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/RED (OR RED/YEL) WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CLUTCH PEDAL POSITION SWITCH (ABOVE CLUTCH PEDAL) CRUISE CONTROL INDICATOR (AUTO CRUISE) CRUISE CONTROL MAIN SWITCH CRUISE CONTROL SWITCH (COMBINATION SWITCH) CRUISE CONTROL UNIT (RIGHT REAR OF ENGINE COMPARTMENT) ENGINE COMPARTMENT FUSE/RELAY BOX ENGINE CONTROL MODULE (BELOW RIGHT CENTER OF DASH) FUSE GRN WIRE HOT AT ALL TIMES HOT IN ACCY OR ON HOT IN ON OR START ILLUM INSTRUMENT CLUSTER J/C 11 J/C 14 J/C 2 J/C 3 J/C 4 J/C 9 JC-20 JUNCTION CONNECTOR (BEHIND LEFT SIDE OF DASH) M/T METER FUSE OFF ON IND. ORG/ WIRE ORG/BLK WIRE PASSENGER COMPARTMENT FUSE BOX (BELOW LEFT SIDE OF DASH) PNK WIRE RED WIRE RED/BLK WIRE RES+ SET/ CST CANCEL SPEEDOMETER ASSEMBLY STARTER STARTER SOLENOID STOP FUSE TRANSAXLE CONTROL MODULE (BEHIND LEFT SIDE OF DASH) TRANSAXLE RANGE SWITCH (LEFT REAR SIDE OF ENGINE COMPARTMENT) WHT WIRE YEL WIRE
