Kia Sephia II (1997-2001) unlock input ground door lock ctrl door lock ctrl lock input Wiring diagram
This page shows the only wiring diagram for the component.unlock input ground door lock ctrl door lock ctrl lock input, which is found in the car Kia Sephia II (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram unlock input ground door lock ctrl door lock ctrl lock input (1 of 1)
1 2 3 4 5 6 7 PNK BATTERY WIRE
2 4 13 14 10 UNLOCK INPUT LOCK INOUT UNLOCK OUTPUT LOCK OUTPUT GROUND
BLK WIRE
DOOR KNOB LOCK SWITCH
DOOR LOCK FUSE
ELECTRONIC TIME CONTROL MODULE (BELOW LEFT SIDE OF DASH)
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
HOT AT ALL TIMES
J/C 4
J/C 5
LEFT REAR DOOR LOCK MOTOR
LOCKED
PNK WIRE
POWER DOOR LOCK RELAY (BEHIND LEFT SIDE OF DASH)
RIGHT REAR DOOR LOCK MOTOR RIGHT FRONT DOOR LOCK MOTOR
UNLOCK INPUT GROUND DOOR LOCK CTRL DOOR LOCK CTRL LOCK INPUT
UNLOCKED
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
