Kia Sephia II (1997-2001) right rear control up Wiring diagram
This page shows the only wiring diagram for the component.right rear control up, which is found in the car Kia Sephia II (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear control up (1 of 1)
AUTO DN UP
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL UNIT)
DOWN
DOWN DOWN
DOWN LEFT FRONT CONTROL
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
HOT IN ON
ILLUMI- NATION
ILLUMINATION
J/C 1
J/C 4
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR CONTROL UP
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
LOCK OUT SWITCH DOWN
MASTER POWER WINDOW SWITCH
P/WIND LH FUSE
P/WIND RH FUSE
PNK PNK WIRE
PNK WIRE
RED WIRE
RIGHT FRONT CONTROL
RIGHT FRONT POWER WINDOW MOTOR
RIGHT FRONT POWER WINDOW SWITCH
RIGHT REAR CONTROL UP
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
UP UP
WHT WIRE
YEL WIRE
Go to component -> Power window circuit -> RIGHT REAR CONTROL UP
