Kia Sephia II (1997-2001) right front power window switch o/d off switch left rear power window switch Wiring diagram
This page shows the only wiring diagram for the component.right front power window switch o/d off switch left rear power window switch, which is found in the car Kia Sephia II (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front power window switch o/d off switch left rear power window switch (1 of 1)
ABS CONTROL UNIT
ABS FUSE
AUDIO FUSE
BACK-UP LIGHT SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CIGAR FUSE
CIGARETTE LIGHTER
DIGITAL CLOCK
ELECTRONIC TIME CONTROL MODULE
ELECTRONIC TIME CONTROL MODULE ABS WARNING MODULE
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
FRESH/ RECIRCU- LATION SWITCH REAR WINDOW DEFROST SWITCH
FROM ENGINE COMPARTMENT FUSE/RELAY BOX (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FUSE
GRN WIRE
HAZARD SWITCH
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMER SWITCH INSTRUMENT CLUSTER CRUISE CONTROL MAIN SWITCH
J/C 11
J/C 14
J/C 19
J/C 3
J/C 7
JC-20
LEFT FRONT SIDE MARKER LIGHT
LEFT HEADLIGHT ASSEMBLY
LEFT LICENSE LIGHT RIGHT REAR LIGHT ASSEMBLY
LEFT REAR LIGHT ASSEMBLY RIGHT FRONT SIDE MARKER LIGHT
LH TAIL FUSE
METER FUSE
PASSENGER COMPARTMENT FUSE BOX (BELOW LEFT SIDE OF DASH)
PNK PNK PNK WIRE
PNK WIRE
POWER MIRROR CONTROLLER
RADIO
RADIO HAZARD SWITCH
RED WIRE
RH TAIL FUSE
RIGHT FRONT POWER WINDOW SWITCH O/D OFF SWITCH LEFT REAR POWER WINDOW SWITCH
RIGHT HEADLIGHT ASSEMBLY
RIGHT LICENSE LIGHT
RIGHT REAR POWER WINDOW SWITCH A/C SWITCH MASTER POWER WINDOW SWITCH
SHIFT LOCK ACTUATOR
TRANSAXLE CONTROL MODULE
TRANSAXLE RANGE SWITCH VEHICLE SPEED SENSOR
TURN SIGNAL FUSE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> RIGHT FRONT POWER WINDOW SWITCH O/D OFF SWITCH LEFT REAR POWER WINDOW SWITCH
