Kia Sephia II (1997-2001) left front light assembly Wiring diagram
This page shows the only wiring diagram for the component.left front light assembly, which is found in the car Kia Sephia II (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front light assembly (1 of 1)
ANTI-LOCK BRAKE CONTROL UNIT
BATTERY
BLK WIRE
CAMSHAFT POSITION SENSOR
CONDENSOR FAN MOTOR
CRANKSHAFT POSITION SENSOR
DATA LINK CONNECTOR (DLC)
ENGINE COMPARTMENT FUSE/RELAY BOX
ENGINE CONTROL MODULE (ECM)
ENGINE COOLING FAN MOTOR
FRONT WASHER MOTOR
GRN WIRE
HORN
J/C 1
J/C 12
J/C 2
LEFT FRONT LIGHT ASSEMBLY
LEFT HEADLIGHT
LT LT
MASS AIRFLOW SENSOR
NCA WIRE
OBD-II DATA LINK CONNECTOR
RED WIRE
RIGHT FRONT LIGHT ASSEMBLY
RIGHT HEADLIGHT
TRANSAXLE CONTROL MODULE (TCM)
YEL WIRE
Go to component -> Ground distribution circuit (1 of 2) -> LEFT FRONT LIGHT ASSEMBLY
