Kia Sephia II (1997-2001) head low fuse Wiring diagram
This page shows the only wiring diagram for the component.head low fuse, which is found in the car Kia Sephia II (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram head low fuse (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION SWITCH
DIMMER SWITCH
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) HEAD HI FUSE
EXTERIOR LIGHTS SYSTEM (TAIL FUSE)
GRN WIRE
HEAD FUSE
HEAD LOW FUSE
HEADLIGHT RELAY
HEADLIGHT SWITCH PARK OFF HEAD
HI BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ON OR ACCY
INSTRUMENT CLUSTER
J/C 1
J/C 2
J/C 3
JC-13
LEFT HEADLIGHT
LIGHT SWITCH
LO FLASH HI
LO HI FLASH
NCA WIRE
PARK OFF HEAD
PNK WIRE
RED WIRE
RIGHT HEADLIGHT
TAILLIGHT RELAY
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit -> HEAD LOW FUSE
